Affordable Heavy-Duty Tilt TV Wall Mount LP73-48T For 43’’~90’’ TVs from china(chinese)

LP73-48T

Affordable Heavy-Duty Tilt TV Wall Mount

For 43’’~90’’ TVs

Description

To address the gap in the niche market of heavy-duty large-sized TV wall mounts, the LP73-48T Affordable Heavy-Duty TV Wall Mount is a reasonable solution. A stiffener structure levels the weight capacity up to 80kg/176lbs to firmly hold 43’’~90’’ TVs. Ample space in the center is perfect for installing the socket outlet and concealing all the messy cables. +10°~-10° toolless tilting mechanism provides the perfect viewing angle. A quick-release spring lock allows TV removal quick and easy and only takes seconds to install. Choose LP73-48T to grasp more market share quickly!

Color:

FEATURES

●Reduced Package Size: relatively lower transport costs and storage fees (perfect for e-commerce platform sellers)

●Automatic Spring Locks with Quick Release Cords: allow TV removal quick and easy

●Heavy-Duty Steel Construction: provides extra strength and durability

●Open Architecture: provides increased ventilation and easier access to wires

●Toolless Tilt: allows for effortless positioning

Reduced Package Size: relatively lower transport costs and storage fees (perfect for e-commerce platform sellers)
Automatic Spring Locks with Quick Release Cords: allow TV removal quick and easy
Heavy-Duty Steel Construction: provides extra strength and durability
Open Architecture: provides increased ventilation and easier access to wires
Toolless Tilt: allows for effortless positioning

SPECIFICATIONS

Product Category:	Tilt TV Wall Mount
Rank:	Standard
Material:	Steel
Metal Sheet Thickness:	Bracket Arm THK=1.8mm cold-rolled sheet,Wall Plate THK=1.8mm cold-rolled sheet (Wall Plate THK=0.071" cold-rolled sheet,Bracket Arm THK=0.071" cold-rolled sheet)
Surface Finish:	Powder Coating
Color:	Fine Texture Black
Dimensions:	60x885x425mm (2.4"x34.8"x16.7")
Fit Screen Size:	43"-90"
Fit Curved TV:	Yes
Mounting Hole Pattern:	VESA & Universal
VESA Compatible:	50x50,75x75,100x100,100x150,150x100,100x200,200x100,150x150,200x200,200x300,300x200,200x400,400x200,300x300,300x400,400x300,600x200,400x400,600x300,600x400,700x400,800x400
Max. Mounting Hole:	845x402mm
Weight Capacity:	80kg (176lbs)

Strength Tested:	4 Times Approved
Profile:	60mm (2.4")
Tilt Range:	+10°~-10°
Screen Freely Tilting:	Yes
Installation:	Solid Wall,Double Stud(406mm/450mm/600mm)
Panel Type:	Detachable Panel
Wall Plate Type:	Fixed Wall Plate
Direction Indicator:	Yes
Cable Management:	No
Anti-theft:	No
Bubble Level:	Hook-on Bubble Level(Included in Components Package)
Accessory Kit Package:	Normal/Ziplock Polybag,Compartment Polybag
Silk Screen:	Can be silkscreen printed

Product Category:	Tilt TV Wall Mount
Rank:	Standard
Material:	Steel
Metal Sheet Thickness:	Bracket Arm THK=1.8mm cold-rolled sheet,Wall Plate THK=1.8mm cold-rolled sheet (Wall Plate THK=0.071" cold-rolled sheet,Bracket Arm THK=0.071" cold-rolled sheet)
Surface Finish:	Powder Coating
Color:	Fine Texture Black
Dimensions:	60x885x425mm (2.4"x34.8"x16.7")
Fit Screen Size:	43"-90"
Fit Curved TV:	Yes
Mounting Hole Pattern:	VESA & Universal
VESA Compatible:	50x50,75x75,100x100,100x150,150x100,100x200,200x100,150x150,200x200,200x300,300x200,200x400,400x200,300x300,300x400,400x300,600x200,400x400,600x300,600x400,700x400,800x400
Max. Mounting Hole:	845x402mm
Weight Capacity:	80kg (176lbs)

Strength Tested:	4 Times Approved
Profile:	60mm (2.4")
Tilt Range:	+10°~-10°
Screen Freely Tilting:	Yes
Installation:	Solid Wall,Double Stud(406mm/450mm/600mm)
Panel Type:	Detachable Panel
Wall Plate Type:	Fixed Wall Plate
Direction Indicator:	Yes
Cable Management:	No
Anti-theft:	No
Bubble Level:	Hook-on Bubble Level(Included in Components Package)
Accessory Kit Package:	Normal/Ziplock Polybag,Compartment Polybag
Silk Screen:	Can be silkscreen printed

VIDEO

How to Install | LP73-48T
